Jeep Renegade (2016-2017) – fuses diagram
Jeep Renegade (2016-2017) – fuse box diagram
Year of production: 2016, 2017
Fuse box in the engine compartment
The engine compartmentfuse panel is located on the left side of the engine compartment.
| Recess | Maxi fuse | Cartridge fuse | Micro fuse | Description |
| F01 | 70 | – | – | Module computer |
| F02 | 70 | – | – | Module computer, rear distribution modules |
| F03 | – | 20 | – | Power supply control computer |
| F04 | – | 30 | – | Electronic brake control module |
| F05 | 70 | – | – | Electric power steering |
| F06 | 20 | – | – | Engine cooling fan |
| F07 | 40 – 1,4Without air conditioning | Engine cooling fan | ||
| 50 – 1.4With air conditioning and all 2.4Models | ||||
| F08 | – | 30 | – | Automatic transmission, GSM |
| F09 | – | – | 5 | Control module motor |
| F10 | – | – | 15 | Horn |
| F11 | – | – | 10 – 1.4 Motors | Supply secondary loads |
| – | – | 25 – 2.4Motors | ||
| F14 | – | – | 7,5 | Radiator „Blow By” |
| – | – | 5 | Pump power „after startup” | |
| F15 | 40 | – | – | Brake control module pump |
| F 16 | – | – | 5 | Engine control module power, automatic transmission |
| F17 | – | – | 10 – 1.4 Engines | Deliver primary loads |
| – | – | 15 – 2.4 Motors | ||
| F18 | – | – | 20 | Rear cargo outlet 12 V Powered by ignition |
| F19 | – | – | 7,5 | Air conditioning compressor |
| F20 | – | – | 5 | Electronic four-wheel driveDrive |
| F21 | – | – | 15 | Fuel pump |
| F22 | – | – | 20 | Power control module motor |
| F23 | – | – | 30 | Heated windshield – if equipped |
| F24 | – | – | 15 | Electronic unit powering the automatic transmission |
| F30 | – | – | 20 CustomerInstalled) | Fixed rear cargo outlet 12 voltbattery power supply |
| F83 | – | 40 | – | Air conditioning fan |
| F84 | – | – | 30 | All-wheeldrivepower supply |
| F87 | – | – | 5 | Automatic gear selectionTransmission |
| F88 | – | – | 7,5 | Heated exterior mirrors |
| F89 | – | – | 30 | Heated rear window |
| F30 | – | – | 5 | IBS sensor (battery charge status) |
Dashboard fuse box (Body Computer Fuse Center).
The controller is located on the left side of the steering column at the bottom of the dashboard.
| Recess | Mini fuse | Description |
| F31 | 7,5 | Flashing lights / electric movement Front seats / fan air conditioning |
| F33 | 20 | Front power window (driver’s side) |
| F34 | 20 | Front power window (passenger side) |
| F36 | 15 | Provide Uconnect® system, air conditioning, alarm, power-folding exterior mirrors, USB port |
| F37 | 10 | Power Forward Collision Warning Plus system, all-wheel drive (AWD), IPC |
| F38 | 20 | Central locking system |
| F42 | 7,5 | Power Under Lock and Key |
| F43 | 20 | Bidirectional pump washer |
| F47 | 20 | Power-operated rear window (driver’s side) |
| F48 | 20 | Power-operated rear window (passenger side) |
| F49 | 7,5 | Supply ParkSense, front dome spotlight, mirror, electric motor folding roof, heated front seats, stabilizer battery, ESC system, ESL |
| F50 | 7,5 | Supply airbag |
| F51 | 7,5 | Power alarm, Front auxiliary light, A/C compressor, Brake pedal switch (NC), Automatic transmission in the nameplate, Compass, Rear view camera, Headlight leveling, Air conditioning |
| F53 | 7,5 | Provide IPC / Starter Device / Keyless Enter-N-Go System. |
| F94 | 15 | Power socket |
Rear cargo fuse / relay assembly
The configuration of the trunk varies depending on the vehicle equipment
A version fuse box
| Recess | Mini fuse | Description |
| F1 | 30 | Inverter |
| F2 | 20 | HIFI audio system |
| F3 | 20 | MY SKIES |
| F4 | 7,5 | Front lumbar adjustment (driver’s side) |
| F5 | 30 | Electric seat (driver’s side) |
| F6 | 7,5 | Electric seat (driver side and passenger side) |
| F7 | 30 | Front seats with lumbar adjustment (driver side and passenger side) |
| F8 | 20 | Front seat heating |
| The fuse box also has a 20 amp fuse for the sliding roof sunshade. | ||
B version fuse box
.
| Recess | Mini fuse | description |
| F1 | 10 | Controller exterior lighting onFilm traileron |
| F5 | 15 | Controller exterior lighting (driver side) |
| F6 | 15 | Controller exterior lighting (passenger side) |
